1. About the System
WhatsApp is a global messaging platform that facilitates real-time communication through text, images, videos, voice notes, and calls. It is designed to be:
- Highly Scalable: Supports billions of users.
- Real-Time: Messages delivered instantly.
- Highly Available: Minimal downtime.
- Secure: End-to-end encryption ensures privacy.
2. Requirements & Goals
Functional Requirements
- User Management: Signup, login, profile updates, and contact management.
- Messaging: Send/receive text, images, videos, and files.
- Real-time Communication: Implemented using WebSockets.
- Group Chats: Users can create and participate in group conversations.
- Voice/Video Calls: Supports one-on-one and group calls.
- Status Updates: Users can post text, images, and videos.
- Notifications: Push and in-app notifications.
- Security: End-to-end encryption for messages and calls.
Non-Functional Requirements
- Scalability: Supports billions of messages daily.
- Low Latency: Instant message delivery.
- High Availability: 24/7 uptime.
- Data Consistency: Message ordering must be maintained.
- Efficient Storage: Optimized storage for messages and media.
3. Capacity Estimations and Constraints
Assumptions
- Daily Active Users (DAU): 50 million
- Messages per User per Day: 20
- Total Messages per Day: 50M × 20 = 1B
- Media Messages: 5% of total messages (50M)
- Average Message Size: 100 bytes for text, 100 KB for media
- Storage Needs:
- Text: 950M × 100B = ~95GB/day
- Media: 50M × 100KB = ~5TB/day
- Total Storage per Day: ~5.1TB
- 5-Year Projection: ~9.3PB
- Bandwidth: ~120 MB/sec
- Requests per Second (RPS): ~24K
4. System APIs
Authentication
- POST /api/login: Authenticate user and return session token.
- POST /api/logout: Logout user.
Messaging
- POST /api/messages: Send a message.
- GET /api/messages: Retrieve messages for a user.
Group Chats
- POST /api/groups: Create a group.
- POST /api/groups/add: Add user to a group.
- POST /api/groups/messages: Send a group message.
Voice/Video Calls
- POST /api/calls/start: Start a call.
- POST /api/calls/end: End a call.
Status Updates
- POST /api/status: Post status update.
- GET /api/status: Retrieve status updates.
Notifications
- POST /api/notifications: Send push notifications.
5. Data Model Design
Tables
- Users: Stores user information.
- Messages: Stores messages with type, content, and timestamps.
- Chats: Represents private chats between users.
- Users_Chats: Maps users and chats (N:M relationship).
- Groups: Stores group details.
- Users_Groups: Maps users and groups (N:M relationship).
Database Choice
- Relational Databases (PostgreSQL): For structured data (users, chats, groups).
- NoSQL (Cassandra, DynamoDB): For messages to ensure scalability.
6. API Design
Get All Chats or Groups
getAll(userID: UUID): Chat[] | Group[]
Get Messages
getMessages(userID: UUID, channelID: UUID): Message[]
Send Message
sendMessage(userID: UUID, channelID: UUID, message: Message): boolean
Join/Leave Group
joinGroup(userID: UUID, channelID: UUID): boolean
leaveGroup(userID: UUID, channelID: UUID): boolean
7. High-Level Architecture
Microservices-Based Architecture
Core Services:
- User Service: Manages user authentication and profile information.
- Chat Service: Handles real-time messaging via WebSockets.
- Notification Service: Sends push notifications.
- Presence Service: Tracks online status.
- Media Service: Handles media uploads and storage.
Inter-Service Communication
- REST API & gRPC for synchronous calls.
- Message Queue (Kafka/RabbitMQ) for asynchronous processing.
8. Scaling and Optimization Strategies
Horizontal Scaling
- Load Balancers (NGINX, HAProxy) distribute traffic.
- Multiple database shards to handle storage efficiently.
Caching
- Redis/Memcached for frequently accessed data (user profiles, messages).
Data Storage Strategy
- Cold Storage: Older messages archived to reduce database load.
- CDN: Distributes media content for reduced latency.
9. Security Considerations
- End-to-End Encryption (E2EE): Ensures message confidentiality.
- OAuth & Token-Based Authentication: Secures API access.
- Rate Limiting & Throttling: Prevents spam attacks.
10. Conclusion
This HLD provides a structured approach to designing WhatsApp’s architecture, ensuring scalability, high availability, and robust security measures.
